Copper Continuous Extrusion Cold Rolling Mill Equipment 700 Kg/H Productivity
1set
MOQ
negotiation
giá bán
Copper Continuous Extrusion Cold Rolling Mill Equipment 700 Kg/H Productivity
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông tin cơ bản
Place of Origin: China
Hàng hiệu: Jingjie
Model Number: TBJ350
Điểm nổi bật:

cold rolling machine

,

cold roll mill

Thanh toán
Packaging Details: Packed in wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 10sets per month
Thông số kỹ thuật
Material type: F16/17mm
Product scope of section: 100mm copper platoon, F45mm copper rod
Motor Power: 110kw
Type: TBJ350
Main motor power: 180kW
Average productivity: 700kg/h
Mô tả sản phẩm



Copper Continuous Extrusion Cold Rolling Mill Equipment 700 Kg/H Productivity



Detailed Product Description

Main Technical Parameters TBJ350 Copper extrusion machine Aluminium extrusion machine
Extrusion wheel nominal diameter 350mm 350mm
Main motor power 180kW 180kW
Installed power 4-12.5m/rpm 16 m/rpm
Extrusion machine speed ead on oxygen free copper rod, pure aluminum, aluminum alloy
Types of materials F16/17mm 15mm
rod diameter 80-1000 mm2 10-600mm2
Product scope of section 100mm copper platoon, F45mm copper rod Flat wire, flat tube 60 mm,
Product maximum width Pipe diameter 30 mm
Average productivity 700kg/h 350 kg/h
Material overflow rate 2-3% 0

Application: copper flat wire, copper busbar, commutator, contact wires for electric locomotive, transformer, big and middle sized motor, high-low voltage switch electric appliance, DC electric commutator and so on

This production line is composed of pay-off⇒(brush foe aluminum rod)⇒straightener⇒main engine⇒ cooling system⇒take-up machine and electrical controlling unit.

One TBJ350 continuous extrusion product line can be used both for copper and aluminum rod just changing extrusion wheel .







Company introduction

Riyue Machinery, former Changzhou Electrician Machinery Plant with more than 40 years history, mainly produces aluminum and copper continuous extrusion machine(conform machine) ,hydraulic drawing machine and automatic tin plate machine for more than 15 years.
♦ The machine can be used to produce copper(aluminum) flat wire ,copper(aluminum) bar,commutator,contact wires for electric locomotive and other solid copper(aluminum)material.
♦ Till now,our products were served in thousands users in the world,such as Russia,Canada,Turkey,Korea,Taiwan,India,Iran and so on.


♦ With floor area of more than 90,000 square meters and building area of more than 40,000 square meters as well as more than 300 employees, the company has complete processing equipments and strong technological strength. It has become a large-scaled company with annual production capacity of more than 200 sets of extruding machines.



♦ Quality makes competitive products, and credit makes brand. Our company strictly adheres to the ISO9001:2000 standard. Any old or new customers at home and abroad are warmly welcomed to have inspection in our company and give us the guidance. We sincerely hope to cooperate with you, develop both sides, and create rosy tomorrow together.



Enterprise perspective: Cast an enterprise last for centuries.

Company spirit: Be united and pragmatic, make pioneering efforts and forge ahead.

Company Policy: To be honest, credit first, customer first.



Our company can perform specific designing and developing according to customers' specific requirements.
